Bluetooth Protocol Analyzer

Bluetooth Tracker

Ultra-Portable BLE and Wi-Fi Protocol Analyzer





BT Tracker



Industry's First Wideband Bluetooth Low Energy sniffer with concurrent capture of Wi-Fi 802.11 1x1 a/b/g/n, raw 2.4 GHz spectrum, HCI (UART, SPI), WCI-2, logic signals, and Audio I2S..



Highlights
  • All-in-One: concurrent capture of Bluetooth Low Energy, Wi-Fi 1x1, raw spectrum, HCI and logic, all synchronized to sub-microsecond precision
  • Wideband Capture: rock-solid capture of all Bluetooth Low Energy channels
  • Extremely Compact: pocket-sized at 7.5 x 7.5 x 1.7 cm (2.9 x 2.9 x 0.7'')
  • USB Powered: ultimately portable, convenient and environmentally friendly
  • Reprogrammable Digital Radio: support for new specifications with a simple software update, without hardware changes
  • Wi-Fi: debug your Wi-Fi a/b/g/n and BLE connections simultaneously, as well as coexistence
  • Raw 2.4 GHz Spectrum Capture: characterize the wireless environment and visualize interferences
  • Professional Software: use the acclaimed, widely adopted and highly flexible Ellisys multi-protocol analysis software.
  • All Protocols and Profiles: best-of-breed protocol decoding
  • Logic Analysis: visualize digital signals such as GPIOs, interrupts, debug ports, etc, concurrently and perfectly synchronized with your BLE and Wi-Fi traffic
  • Free Maintenance: free lifetime software updates as well as free fully-featured viewer software with unlocked hardware that can be used on any computer



Explorer

Industry’s First All-in-One Sniffer

Capturing wireless traffic is a very important aspect of Bluetooth debugging, but other information is equally important for understanding the big picture. The Ellisys Bluetooth Tracker sniffer supports one-click concurrent and tightly synchronized capture of:

  • Bluetooth Low Energy
  • Wi-Fi 1x1 802.11 a/b/g/n [Enterprise]
  • 2.4 GHz Spectrum [Pro]
  • UART HCI (2 ports) and SPI HCI (2 ports) [Pro]
  • Logic signals [Pro]
  • Wireless Coexistence Interface 2 (WCI-2) [Enterprise]

Datasheet Tracker


Industry’s First Reconfigurable Bluetooth Digital Radio

With its innovative reconfigurable radio, the Ellisys sniffer can uniquely be updated by software to support changes in the specification, without any change to the hardware, and even without any interaction from the user. For instance, this flexibility allowed for the addition of next-generation Bluetooth baseband features several months before the specification was officially released. Additionally, the Tracker comes with free lifetime software updates, so all customers can benefit from these great additions free-of-charge.
